Double Wall Glass Bioreactor
25 Years Experience Bioreactor/Fermenter Manufacturer
Your Reliable Chinese Double Wall Glass Bioreactor Suppliers : Ferbio
Ferbio is a leading bioreactor manufacturer in China.Ferbio produces various types of biological fermenters, capable of producing bioreactors with volumes ranging from 0.1L to 1000KL, and provides technical services to provide intelligent and personalized comprehensive solutions for bioreactor processes. The products provided by Ferbio are classified by scale, there are seed fermenters, pilot scale bioreactors, and industrial scale bioreactors; In terms of usage, there are vaccine bioreactors, cell culture bioreactors, bacterial bioreactors, plant cell bioreactors, etc. In addition, Ferbio also has supporting equipment for bioreactors, such as air compressors, chillers, steam generators, centrifuges, etc. Ferbio has a large team of experienced fermentation process, biochemical equipment, and chemical technology engineers, with many renowned experts and scholars serving as technical consultants for the company. Ferbio always puts customer needs first and insists on putting customers at the center.
Double Wall Glass bioreactor
A double wall glass bioreactor, also known as a jacketed glass bioreactor, features two concentric glass walls. The inner vessel holds the culture medium and cells, while the outer wall (jacket) allows a thermal fluid—such as water, oil, or glycol—to circulate, enabling precise temperature control of the culture environment.
The Double Wall Glass Bioreactor is a state-of-the-art laboratory bioreactor system designed for precise, temperature-controlled cultivation of microbial, mammalian, plant, and insect cells. Built from high-purity borosilicate glass with a robust dual-wall (jacketed) design, this bioreactor allows researchers and process engineers to maintain exceptional thermal stability and observe their cultures in real time through a crystal-clear vessel.
Double Wall Glass Bioreactor has Strict Quality Supervision System
Ideal for academic research, biopharmaceutical R&D, and pilot-scale production, the double wall glass bioreactor offers high modularity, full compatibility with standard lab sensors and automation. Whether you’re working with CHO cells, stem cells, yeast, or bacteria, this system provides the visibility and control needed for consistent, scalable, and reproducible bioprocessing.
Know More About Double Wall Glass Bioreactor
| Parameter | Description |
| Total volume | 0.2L~30L |
| Working volume | 50%~70% |
| Tank | Jacket glass vessel. Lid made by stainless steel with ports, condenser on the cover |
| Stirring system | Mechanical drive or Magnetic drive on top , 3 six-blade paddle and 1 foam breaker, each paddle height adjustable. Stir speed: 50~1000rpm/50-500rpm |
| Sterilization | Off-site sterilization (Autoclave) |
| Gas control | Control by rotor meter, air flow 2vvm. |
| Feeding | Automatically feeding by peristaltic pump |
| Anti-foam control | Automatically add antifoamer by peristaltic pump |
| Temperature control | Auto-control, electric heating range water source add 5℃ to 70℃ |
| PH control | PH 2.00-12.00±0.1, auto-control adding acid/base by peristaltic pump, pH sensor from Hamilton/Mettler, Switzerland. |
| DO control | 0-150±3% displaying precision 0.1%, DO sensor from Hamilton/Mettler, Switzerland. DO coupling with agitation, oxygen. |
| Sampling | Manual sampling |
| Control parameters | 10 or 15 inch touch screen , Siemens PLC with control parameters (stirring, pH, DO, temperature, feeding, alarm, gas etc.), data analysis, data record, data output, language(RU/EN/CN) and other customized functions |
| Optional configuration | We can customize the parameters of double wall glass bioreactor according to customer needs，such as Remote control, Mass flow meter(auto control gas), O2/N2/CO2, gas(CO2) exhaust analysis, Level sensor, Turbidity(OD) sensor, ORP sensor, Weight system, Live cell sensor（Biomass）, Printing, Siemens touch screen, etc. |
Other Products
Send Inquiry
Our Advantages
Extensive Manufacturing Experience
With over 20 years of bioreactor production expertise, our factory delivers high-performance systems trusted by global biotech and pharmaceutical companies.
Customized Solutions
We provide tailor-made bioreactor designs to meet diverse application needs, including microbial fermentation, cell culture, and pilot-scale production. ers with a full range of solutions.
Full Range of Products
From lab-scale glass fermenters to industrial stainless steel systems, we offer a complete portfolio to support all stages of bioprocess development.
Global Technical Support
Our experienced engineering and after-sales teams provide responsive service and on-site support worldwide.
