Single Use Bioreactor
Over 25 years production experience
Your Reliable Chinese Single Use Bioreactor Supplier : Ferbio
Ferbio is a leading bioreactor manufacturer in China.Ferbio produces various types of biological fermenters, capable of producing bioreactors with volumes ranging from 0.1L to 1000KL, and provides technical services to provide intelligent and personalized comprehensive solutions for bioreactor processes. The products provided by Ferbio are classified by scale, there are seed fermenters, pilot scale bioreactors, and industrial scale bioreactors; In terms of usage, there are vaccine bioreactors, cell culture bioreactors, bacterial bioreactors, plant cell bioreactors, etc. In addition, Ferbio also has supporting equipment for bioreactors, such as air compressors, chillers, steam generators, centrifuges, etc. Ferbio has a large team of experienced fermentation process, biochemical equipment, and chemical technology engineers, with many renowned experts and scholars serving as technical consultants for the company. Ferbio always puts customer needs first and insists on putting customers at the center.
Introduction to Single use Bioreactor
Single-use bioreactor (also known as a disposable bioreactor) is a bioreactor that uses disposable bags instead of culture containers.This refers to bioreactors that are lined with plastic in contact with cell culture. This type of bioreactor can be made into lined tanks with stirring, wave hybrid reactors, and orbital oscillating reactors.This kind of reactor has the advantages of low cost and favorable hygiene certification.
Single use Bioreactor Feature
1.Tray replaced rapidly.10L trays, 20L trays, 50L trays replaced easily
2.Suspension culture and adherent culture.Suitable for different cell culture bags, e.g. suspension cell culture and adherent cell culture. Continuous perfusion culture for adherent cell is achieved easily with our patented fabric carrier bag
3.Batch culture and perfusion culture of suspension cells.Perfusion membrane cell culture bag is used for the perfusion culture and high-density culture of suspension cells and the N-lscale-up
4.Adherent cell trypsinization, transfer and scale up.Fabric carrier cell culture bags can achieve amount cell culture adherent, and then trypsinizate and prepare amount adherent seed cells into next process
Know More About Single use Bioreactor
| Tray size | 10L | 20L | 50L | ||
| Total volume(suspension culture) | 2L | 5L | 10L | 20L | 50L |
| Total volume(adherent culture) | 2L | 5L | 10L | 20L | 50L |
| Max. working volume | IL | 2.5L | 5L | 10L | 25L |
| Control system | Siemens PLC, 15-inch color touch screen, Ethernet interface, USB interface | ||||
| Temperature control | Heating plate, PID automatic control, accuracy: ±0.2°C; Temperature control range: 5-40°C above | ||||
| Rocker speed | l-40rpm | ||||
| Tilt angle | 1-12° | ||||
| Gas※ | 3 thermal mass flow controllers (Air/O2/CO2), 1 thermal mass flow controller with 3 gas mixer optional | ||||
| Exhaust ※ | Exhaust condenser, exhaust filter heater optional | ||||
| Exhaust analysis | O2(0-50%), CO2 (0-15%) | ||||
| Pressure detection | Range:-100mbar——l00mbar; Stop air intake when it is exceeded. | ||||
| pH | Single-use pH probe, control range: 6-8, accuracy:±0.05pH; PID control; cascaded by gas flow, peristaltic pump, etc. | ||||
| DO | Single-use DO probe, control range: 0-100%, accuracy:±3%; PID control; cascaded by rocker speed, MFC, etc. | ||||
| Pumps※ | 4fixed-speed peristaltic pumps,customized feeding/acid feeding/alkali feeding/ discharging etc. 25RPM or 100RPM variable speed optional | ||||
| Load cell | Load: 0-50kg, accuracy: ± (0.050 +1% loading sampling) kg; cascaded by pumps | ||||
| Utilities | Air/O2/CO2, pressure: 15-20PSIG | ||||
| Signal interface | Optional | ||||
| Power supply | AC220V,50/60HZ, 10A | ||||
Our Factory
The following picture shows the production workshop of Ferbio.
